Nearest Time Service

Returns the observation closest to the time requested

Request Format

A Nearest Time request is an HTTP URL with the following form:

https://api.synopticdata.com/v2/stations/nearesttime

Acquiring data from this web service requires certain parameters. When encoding URLs, all parameters are separated using the ampersand (&) character and their value is indicated by an equal sign (=). Below is a list of accepted parameters.

• token (required), Your application’s API token. This is used to identify who is requesting API data. You are never required to use multiple tokens, but you can use as many as you need. Learn more in our tokens overview.

• attime(required), The date and time of the closest observation to be returned. In the form of YYYYMMDDhhmm Where YYYY is year, MM is month, DD is day, hh is hour, and mm is minutes. For example: attime=201306011800. All times are requested in UTC, but may be returned in either UTC or Local time format for each station. See the obtimezone parameter.

• within, Restricts the response to observations to a time window ending at the current observation, i.e. within=60 would return only observations within the last 60 minutes.

Optional Parameters

• One or more station selection parameters (optional). Including no station selections will return results for all stations. This can result in extremely large results for services that support it.

• within, Restricts the response to observations to a time window ending at the current observation, i.e. within=60 would return only observations within the last 60 minutes.

• obtimezone (UTC, local), Indicates if the time zone of the response is in UTC (GMT) or the local timezone of the station where the data was observed. A value of either UTC or local. If omitted the default is UTC. Set the timezone used on the observation output (input times are always UTC) Example: obtimezone=local

• showemptystations (off, on), Indicates if stations with no observations for the requested time span will be returned. Often when querying a large group of stations there will be stations that do not meet the criteria of additional request arguments. Setting this value to “on” will return any station meeting the geographical or network group, even if there is no observation data available.

• units (metric, english, [custom format]), Defines the unit of measure for the data to be returned in. By default all data is returned in metric units. For standard measurements used by many in the United States “english” will fill most needs. There is also the ability to support custom unit configurations. This is achieved by accessing the variable group such as “temp” and setting the desired unit using a pipe (|) character, which can then be separated with commas. The following list describes the available units for each variable group.

  • temp (C, F, K), Temperature: Celsius, Fahrenheit and Kelvin.
  • speed (mps, mph, kph, kts), Speed/Velocity: Meters per second, miles per hour, kilometers per hour, knots.
  • pres (pa, mb), Pressure: Pascals, millibars.
  • height (m, ft), Height: Meters, feet.
  • precip (mm, cm, in), Precipitation: Millimeters, centimeters, inches.
  • alti (pa, inhg), Altimeter: Pascals, inches mercury.

  Furthermore, it is possible to modify one of the preset settings (metric/english). This is achieved by appending a variable group and unit to the parameter string with a comma. For example, to use “english” units with altimeter in inHg the parameter would be units=english,alti, inhg.

• hfmetars (1, 0) Disable (defalut enabled) use of High Frequency NOAA METAR data. This is a variant of the hourly NWS/FAA airport data where observations are recorded approximately every 5 minutes. A value of 0 will exclude these data from data returns

Response Format Parameters

• timeformat, Defines a time format that all time stamps in the data response to be formatted to. By default the API will return time values in ISO 8601 format. This behavior can be changed by passing a string with a valid strftime expression. Below are some common examples.

  • timeformat=%m/%d/%Y at %H:%M would yield “06/22/2017 at 17:06”
  • timeformat=%b%20%d%20%Y%20-%20%H:%M would yield “Jun 22 2017 - 17:06”
  • timeformat=%s returns Unix/POSIX time in terms of seconds.

• output (json, xml, geojson), Indicates the response format of the request. It’s recommend to use the JSON format which there are well supported parsing libraries in all major languages. Below are some of the caveats of using a format other than JSON.

  • GeoJSON will only return the best guess sensor if the station has multiple sensors of the same type.

Data Checks and Quality Control

By default, the API does not return data that has been flagged as non-plausible by the Synoptic Range Check, e.g. a temperature value of 200C. It does provide a series of URL arguments that allow the retrieval of removed data as well as their flags.

If the qc parameter is omitted then the API will return data while assuming the following QC parameters: qc=on, qc_remove_data=on, qc_flags=off and qc_checks=sl_range_check. Below is an explanation of parameters that control the application of data checks (QC) to the data.

• qc (on, off), Indicates the application behavior of the data check (QC) attributes on the data requested. If set to “off” then all data will be returned without data checks and quality control (this is not recommended). It is possible to target a particular Synoptic data check or ask for the entire Synoptic test suite, i.e. qc=on. Regardless if any data checks are returned, a "QC_FLAGGED: [bool]" key will appear in the JSON response inside each "STATION" element. Data checks will be in a key titled QC.

  Note: The existence of a data check flag for an observation is not necessarily an indication of invalid or inaccurate data. For a detailed explanation how to apply data checks and how to leverage them, please click here to read more. Optional Output formatting and usability parameters

• qc_remove_data (on, off, mark), Indicates the response behavior for an observation that fails a user specified data check.

  • “off” returns the data values even if a data check failure is present for that data.
  • “on” removes failed data values with a “null”.
  • “mark” replaces failed data with a value of “false”.

• qc_flags (on, off) Indicates whether the data checks are returned alongside any data that failed a requested check. If “on” then the data checks will be returned in the "STATION[n].QC.sensor_name" block.

• qc_checks ([flag name], [flag source], all) defines a list of data checks applied to data values. The settings of other QC parameters determines how the data and data checks are returned.

  • “all” will return any data check in our system.
  • “flag name” allows the targeting of a flag by name or a list (comma separated) of flags.
  • “flag source” allows targeting a data check provider i.e. “synopticlabs” for Synoptic.

Some common examples of modifying the default qc state are:

• qc_checks=synopticlabs,ma_range_check, Applies the Synoptic test suite and MADIS range check
• qc_checks=synopticlabs,madis, Applies the Synoptic and MADIS test suites.

Request Response

JSON Format

The Nearest Time service will return its results in a single organized and self describing JSON object. At a minimum, every request will return a JSON object with a "SUMMARY" field.

An example JSON response would be:

{
  "UNITS": {
    "solar_radiation": "W/m**2"
  },
  "QC_SUMMARY": {
    "QC_TESTS_APPLIED": ["sl_range_check"],
    "TOTAL_OBSERVATIONS_FLAGGED": 0,
    "PERCENT_OF_TOTAL_OBSERVATIONS_FLAGGED": 0
  },
  "STATION": [{
    "STATUS": "ACTIVE",
    "MNET_ID": "153",
    "PERIOD_OF_RECORD": {
        "start": "1997-01-01T00:00:00Z",
        "end": "2017-08-21T05:33:00-0600"
    },
    "ELEVATION": "4806",
    "NAME": "U of U William Browning Building",
    "QC_FLAGGED": false,
    "STID": "WBB",
    "SENSOR_VARIABLES": {
        ...
    },
    "ELEV_DEM": "4738",
    "LONGITUDE": "-111.84755",
    "STATE": "UT",
    "SENSOR_VARIABLES": {
        "date_time": { "date_time": { } },
        "air_temp": {
            "air_temp_set_1": {
                "position": ""
            }
        }
    },
    "OBSERVATIONS": {
      "solar_radiation_value_1": {
        "date_time": "2017-08-21T05:33:00-0600",
        "value": 42
      }
    },
  }],
  "SUMMARY": {
    "DATA_QUERY_TIME": "2.94498825073 ms",
    "RESPONSE_CODE": 1,
    "RESPONSE_MESSAGE": "OK",
    "METADATA_RESPONSE_TIME": "0.0970363616943 ms",
    "DATA_PARSING_TIME": "3.09109687805 ms",
    "TOTAL_DATA_TIME": "12.0379924774 ms",
    "NUMBER_OF_OBJECTS": 1,
  }
}

• SUMMARY{}

  • NUMBER_OF_OBJECTS, (always returned) is a integer value of the number of stations returned.

  • RESPONSE_CODE, (always returned) is a numerical code indicating the status of the request.

    • “1” = “OK”
    • “2” = “Zero Results”
    • “200” = “Authentication failure”
    • “400” = “Violates a rule of the API”
  • RESPONSE_MESSAGE, (always returned) is a string explaining the RESPONSE_CODE.
  • RESPONSE_TIME, (always returned) server time to process the request.

• STATION[]

  • SENSOR_VARIABLES[], summary of variables in the OBSERVATIONS element.
  • OBSERVATIONS[], contains all the observational data.
  • QC[], contains all the data attributes.
  • QC_FLAGGED, boolean value indicating data check attributes are returned (if requested).

• QC_SUMMARY{}

  • QC_TESTS_APPLIED[], a list of data checks that were applied to the data.
  • TOTAL_OBSERVATIONS_FLAGGED, number of observations that have additional data check attributes.
  • PERCENT_OF_TOTAL_OBSERVATIONS_FLAGGED, floating point number indicating the percentage of the observations that have additional data check attributes.
